PRODUCT INTRODUCTION
The UAD-XTC-CZGL01 vehicle-mounted system includes a four-sided phased array radar, full-frequency spectrum detection, electro-optical tracking, and UAV jamming equipment. It detects, tracks, and interferes with UAVs, causing them to hover, land, or return, preventing them from entering the defense zone and ensuring low-altitude airspace safety.
Omnidirectional detection interference
Vehicle-mounted design adaptable to various vehicles; completes UAV detection and countermeasures with minor modifications.
Vehicle integrated design
Adaptable to various vehicles; completes UAV detection and countermeasures with minor modifications.
Prevent multiple models
20-6000MHz interference for multi-frequency band drone disruption, detecting and defending against 99% of UAV models.
Long interference distance
Detection >1.5km, Counter >1km (varies by environment/model).
Mobile deployment
Flexibly deployable in areas unsuitable for fixed installations; supports standalone or networked deployment.
One on one fixed system plan
Customized intelligent solutions from consultation to installation, tailored to customer needs.
 |
|||
| PERFORMANCE INDEX | |||
| Radar System | System: Phased array + all-digital transceiver, DBF technology Mode: Pulsed Doppler Detection range: 1500m (RCS -0.01m²) Coverage: 0°-360° Target capacity: 40 sorties |
||
| Spectrum Detection | Coverage: 20MHz-6GHz Detection range: 5-7km radius Positioning response: ≤5s Target capacity: 50 sorties |
||
| Radio Jamming | Frequency: 433MHz, 915MHz, 1.5GHz, 2.4GHz, 2.5GHz Interference radius: Open area ≤3000M, Urban environment ≤1000M |
||
| Electro-Optical System | Infrared Camera: – Detector: Vanadium oxide uncooled – Waveband: 8-14μm – Resolution: 640×512 – NETD: <40mK @25℃, f#1.0 – Frame Rate: 50Hz – Min Focus Distance: 30mVisible Camera: – Sensor: 1/2.8″ CMOS, 2MP – Resolution: 1920×1080 – Zoom: 30X Optical + 12X Digital – FOV: 63.7°(Wide)-2.3°(Tele) – Min Illumination: 0.013 lx (ICR On) – Tracking Distance: 1.2km (Phantom 3) – Tracking Accuracy: ±1 pixel |
||
